| Weight |
62g ± 1g |
| Size |
40.5*20*38mm |
| Control System |
(+)Pulse Width Control 1500usec Neutral |
| Operating Voltage |
6.0~7.4Volts |
| Operating Temperature Range |
(-)10 to +50 degree C |
| Operating Speed (6.0V) |
0.14sec/60° at no load |
| Operating Speed (7.4V) |
0.12sec/60° at no load |
| Stall Torque (6.0V) |
22kg.cm |
| Stall Torque (7.4V) |
25kg.cm |
| Operating Angle |
45deg.one side pulse traveling 500 usec |
| Direction |
Anticlockwise/Pulse Traveling 1000~2000usec |
| Current Drain (6.0V) |
20mA/idle and 100mA no load operating |
| Current Drain (7.4V) |
20mA/idle and 150mA no load operating |
| Stall Current |
2.5A/2.8A |
| Dead Band Width |
4usec |
| Motor Type |
NdFeB |
| Bearing Type |
Dual ball bearing |
| Horn gear spline |
25T |
| Gear Type |
Metal |
| Connector Wire Length |
300mm±5mm |
| Wire info |
Brown/Black = Negative |
| Red = Positive |
| Orange/White = Signal |
